Model EE Dimensions:
Dimensions for Reference Use Only: Imperial fittings in Inch, Metric fittings
in mm, U.S.O.)
Note: The EE (Extended Elbow) is designed to be
higher than a ME ( Male Elbow) of the same size, so that
when installed side by side the EE can be rotated above the ME and the
tube from the EE can go over the ME.
|
Part
No.
|
Tube
OD
|
T
Pipe
Size
|
A
|
B
|
C
|
E
|
H
|
P
|
WEIGHT
(g)
|
|
EE5/32
10-32
|
5/32
|
10-32UNF
|
0.16
|
1.36
|
0.61
|
0.70
|
0.39
|
0.41
|
15.2
|
|
EE
5/32 N1/8
|
5/32
|
NPT1/8
|
0.31
|
1.48
|
0.61
|
0.70
|
0.39
|
0.41
|
16.8
|
|
EE
3/16 N1/8
|
3/16
|
NPT1/8
|
0.30
|
1.53
|
0.67
|
0.75
|
0.39
|
0.41
|
17.8
|
|
EE
3/16 N1/4
|
3/16
|
NPT1/4
|
|
|
0.67
|
|
|
|
|
|
EE
3/16 N3/8
|
3/16
|
NPT3/8
|
0.46
|
1.89
|
0.67
|
0.75
|
0.67
|
0.43
|
39.8
|
|
EE
1/4 N1/8
|
1/4
|
NPT1/8
|
0.40
|
1.64
|
0.68
|
0.85
|
0.47
|
0.52
|
22.8
|
|
EE
1/4 N1/4
|
1/4
|
NPT1/4
|
0.36
|
1.82
|
0.68
|
0.85
|
0.56
|
0.52
|
33.1
|
|
EE
1/4 N3/8
|
1/4
|
NPT3/8
|
0.45
|
1.94
|
0.68
|
0.85
|
0.67
|
0.52
|
40.0
|
|
EE
5/16 N1/8
|
5/16
|
NPT1/8
|
0.37
|
1.81
|
0.73
|
0.90
|
0.47
|
0.58
|
32.5
|
|
EE
5/16 N1/4
|
5/16
|
NPT1/4
|
0.39
|
1.90
|
0.73
|
0.90
|
0.56
|
0.58
|
34.4
|
|
EE
5/16 N3/8
|
5/16
|
NPT3/8
|
0.41
|
2.01
|
0.73
|
0.90
|
0.67
|
0.58
|
41.2
|
|
EE
3/8 N1/4
|
3/8
|
NPT1/4
|
0.34
|
2.17
|
0.83
|
1.10
|
0.69
|
0.71
|
62.4
|
|
EE
3/8 N3/8
|
3/8
|
NPT3/8
|
0.45
|
2.17
|
0.83
|
1.10
|
0.69
|
0.71
|
58.5
|
|
EE
3/8 N1/2
|
3/8
|
NPT1/2
|
0.54
|
2.56
|
0.83
|
1.10
|
0.88
|
0.71
|
116.6
|
|
EE
1/2 N1/4
|
1/2
|
NPT1/4
|
0.43
|
2.50
|
0.93
|
1.13
|
0.88
|
0.86
|
122.7
|
|
EE
1/2 N3/8
|
1/2
|
NPT3/8
|
0.43
|
2.47
|
0.89
|
1.16
|
0.75
|
0.86
|
85.5
|
|
EE
1/2 N1/2
|
1/2
|
NPT1/2
|
0.51
|
2.60
|
0.89
|
1.16
|
0.88
|
0.86
|
123.4
|
|
|
|
|
|
|
|
|
|
|
|
|
Part
No.
|
Tube
OD
|
T
Pipe
Size
|
A
|
B
|
C
|
E
|
H
|
P
|
WEIGHT
(g)
|
|
EE
4 M5
|
4
|
M5
|
5.4
|
36.1
|
14.4
|
17.8
|
10.0
|
10.6
|
15.4
|
|
EE
4 M6
|
4
|
M6
|
5.1
|
35.2
|
14.6
|
17.8
|
10.0
|
10.6
|
15.7
|
|
EE
4 1/8
|
4
|
R1/8
|
7.3
|
36.8
|
14.4
|
17.8
|
10.0
|
10.6
|
14.0
|
|
EE
4 R1/4
|
4
|
R1/4
|
8.9
|
36.4
|
13.8
|
17.8
|
14.0
|
10.6
|
21.8
|
|
EE
6 M5
|
6
|
M5
|
6.2
|
39.0
|
15.3
|
20.6
|
12.0
|
13.5
|
22.8
|
|
EE
6 M6
|
6
|
M6
|
5.8
|
39.6
|
16.1
|
20.6
|
12.0
|
13.5
|
23.2
|
|
EE
6 R1/8
|
6
|
R1/8
|
7.7
|
38.8
|
15.7
|
20.6
|
12.0
|
13.5
|
21.4
|
|
EE
6 R1/4
|
6
|
R1/4
|
8.9
|
45.0
|
15.5
|
20.6
|
14.0
|
13.5
|
30.4
|
|
EE
6 R3/8
|
6
|
R3/8
|
10.2
|
44.9
|
16.1
|
20.6
|
17.0
|
13.5
|
40.8
|
|
EE
6 R1/2
|
6
|
R1/2
|
12.7
|
48.1
|
15.8
|
20.6
|
21.0
|
13.5
|
63.5
|
|
EE
8 R1/8
|
8
|
R1/8
|
7.3
|
42.2
|
16.7
|
21.8
|
14.0
|
14.7
|
29.6
|
|
EE
8 R1/4
|
8
|
R1/4
|
9.2
|
46.7
|
16.4
|
21.8
|
14.0
|
14.7
|
31.8
|
|
EE
8 R3/8
|
8
|
R3/8
|
10.0
|
46.5
|
16.6
|
21.8
|
17.0
|
14.7
|
42.1
|
|
EE
8 R1/2
|
8
|
R1/2
|
11.6
|
52.7
|
16.5
|
21.8
|
21.0
|
14.7
|
66.8
|
|
EE
10 R1/8
|
10
|
R1/8
|
7.8
|
53.1
|
20.7
|
26.8
|
17.0
|
18.4
|
61.9
|
|
EE
10 R1/4
|
10
|
R1/4
|
8.8
|
56.3
|
20.5
|
26.7
|
17.0
|
18.2
|
61.2
|
|
EE
10 R3/8
|
10
|
R3/8
|
11.0
|
57.0
|
20.5
|
26.7
|
17.0
|
18.2
|
55.5
|
|
EE
10 R1/2
|
10
|
R1/2
|
12.9
|
|
20.2
|
26.8
|
21.0
|
|
|
|
EE
12 R1/4
|
12
|
R1/4
|
8.9
|
62.6
|
20.6
|
28.2
|
19.0
|
20.3
|
90.3
|
|
EE
12 R3/8
|
12
|
R3/8
|
10.7
|
62.9
|
20.6
|
28.2
|
19.0
|
20.3
|
82.6
|
|
EE
12 R1/2
|
12
|
R1/2
|
12.1
|
|
20.6
|
28.2
|
21.0
|
20.3
|
|
|
|
