Model CC Dimensions:
Dimensions for Reference Use Only: Imperial fittings
in Inch, Metric fittings in mm, U.S.O.

Compact Male Connector (with Internal Hex and
round body)
|
|
PART
NO.
|
TUBE
OD
|
T
PIPE SIZE
|
A
|
B
|
C
|
H
(dia.)
|
Int.
Hex
|
X
|
Y
|
WEIGHT (g)
|
|
CC
1/8 10-32
|
1/8
|
10-32UNF
|
0.21
|
0.90
|
0.73
|
0.40
|
5/64
|
0.38
|
0.46
|
6.0
|
|
CC
1/8 N1/8
|
1/8
|
NPT1/8
|
0.30
|
0.84
|
0.54
|
0.41
|
3/32
|
0.38
|
0.46
|
7.7
|
|
CC
5/32 10-32
|
5/32
|
10-32UNF
|
0.21
|
0.89
|
0.65
|
0.40
|
3/32
|
0.38
|
0.46
|
6.0
|
|
CC
5/32 N1/8
|
5/32
|
NPT1/8
|
0.30
|
0.84
|
0.50
|
0.41
|
3/32
|
0.38
|
0.46
|
7.7
|
|
CC
5/32 N1/4
|
5/32
|
NPT1/4
|
0.41
|
0.92
|
0.67
|
0.53
|
3/32
|
0.38
|
0.46
|
14.0
|
| C
1/4 10-32
|
1/4
|
10-32UNF
|
0.30
|
0.91
|
0.63
|
0.47
|
5/64
|
0.45
|
0.53
|
7.7
|
| CC
1/4 N1/8
|
1/4
|
NPT1/8
|
0.30
|
0.91
|
0.63
|
0.47
|
5/32
|
0.45
|
0.53
|
7.7
|
| CC
1/4 N1/4
|
1/4
|
NPT1/4
|
0.41
|
0.97
|
0.63
|
0.53
|
5/32
|
0.45
|
0.53
|
12.8
|
|
CC
3/8 N1/4
|
3/8
|
NPT1/4
|
0.42
|
1.34
|
0.78
|
0.67
|
7/32
|
0.66
|
0.74
|
22.2
|
|
CC
3/8 N3/8
|
3/8
|
NPT3/8
|
0.44
|
1.24
|
0.89
|
0.67
|
5/16
|
0.66
|
0.74
|
22.4
|
|
CC
1/2 N1/4
|
1/2
|
NPT1/4
|
0.38
|
1.38
|
0.81
|
0.79
|
1/4
|
0.79
|
0.88
|
29.8
|
|
|
