Model CU Dimensions:
Dimensions for Reference Use Only: Imperial fittings
in Inch, Metric fittings in mm, U.S.O.
|
|
Tube
OD
|
C
|
E
|
F
|
P
|
X
|
Y
|
D1
|
WEIGHT
(g)
|
|
CU-1/8
|
1/8
|
0.56
|
0.71
|
0.28
|
0.42
|
0.38
|
0.46
|
0.08
|
7.7
|
|
CU-5/32
|
5/32
|
0.56
|
0.71
|
0.28
|
0.42
|
0.38
|
0.46
|
0.08
|
7.7
|
|
CU-3/16
|
3/16
|
0.58
|
0.75
|
0.30
|
0.45
|
0.43
|
0.51
|
0.08
|
9.3
|
|
CU-1/4
|
1/4
|
0.60
|
0.83
|
0.37
|
0.53
|
0.47
|
0.55
|
0.12
|
11.7
|
|
CU-5/16
|
5/16
|
0.62
|
0.88
|
0.41
|
0.58
|
0.54
|
0.61
|
0.12
|
14.2
|
|
CU-3/8
|
3/8
|
0.76
|
1.09
|
0.47
|
0.72
|
0.65
|
0.74
|
0.12
|
27.3
|
|
CU-1/2
|
1/2
|
0.79
|
1.13
|
0.56
|
0.85
|
0.79
|
0.88
|
0.10
|
38.9
|
|
|
|
|
|
|
|
|
|
|
|
|
CU-4
|
4
|
13.5
|
18.3
|
7.2
|
10.7
|
9.7
|
11.6
|
2.0
|
7.5
|
|
CU-6
|
6
|
14.2
|
20.5
|
9.6
|
13.2
|
11.5
|
13.6
|
3.0
|
11.7
|
|
CU-8
|
8
|
15.9
|
22.5
|
9.8
|
14.7
|
13.6
|
15.6
|
3.0
|
14.3
|
|
CU-10
|
10
|
19.8
|
27.4
|
11.8
|
18.3
|
16.0
|
18.3
|
3.0
|
26.5
|
|
CU-12
|
12
|
20.5
|
29.6
|
14.1
|
21.6
|
18.5
|
21.4
|
2.5
|
37.3
|
|
|
