Flow Control Model CV Specifications and Dimensions:
Dimensions for Reference Use Only: Imperial fittings in Inch, Metric fittings
in mm, U.S.O.
 | Complete rotation of the valve body around the bolt allows for
optimum positioning of tubing |
| Compact in size provide space saving installations |
| Special adjustment needle design allows large adjustment ranges with
high precision |
| Adjustment needles and banjo bodies are retained, preventing
accidental loss of needle or lock nut |

Meter Out Angle Control Valve |
|
PART
NO.
|
TUBE
OD
|
T
PIPE
SIZE
|
A
|
B
|
C
|
D
|
E
|
H
|
P
|
WEIGHT
(g)
|
|
CV
1/8 10-32
|
1/8
|
10-32UNF
|
0.16
|
0.43
|
0.47
|
0.16 |
0.80 |
0.31 |
0.42
|
8.0
|
|
CV
1/8 N1/8
|
1/8
|
NPT
1/8
|
0.34
|
0.55
|
0.56
|
0.16
|
0.87
|
0.44
|
0.43
|
18.0
|
| CV
5/32 10-32
|
5/32
|
10-32UNF |
0.16
|
0.43
|
0.47
|
0.16 |
0.80 |
0.31 |
0.42
|
8.0
|
|
CV
5/32 N1/8
|
5/32
|
NPT1/8
|
0.34
|
0.55
|
0.56
|
0.16
|
0.87
|
0.44
|
0.43
|
18.0
|
|
CV
3/16 N1/8
|
3/16
|
NPT1/8
|
0.34
|
0.56
|
0.56
|
0.19
|
0.95
|
0.38
|
0.45
|
18.0
|
|
CV
1/4 10-32
|
1/4
|
10-32UNF
|
0.21
|
0.46
|
0.60
|
0.26
|
0.94
|
0.31
|
0.52
|
9.0
|
|
CV
1/4 N1/8
|
1/4
|
NPT1/8
|
0.34
|
0.58
|
0.60
|
0.26
|
0.94
|
0.44
|
0.52
|
18.6
|
|
CV
1/4 N1/4
|
1/4
|
NPT1/4
|
0.42
|
0.71
|
0.61
|
0.26
|
1.04
|
0.56
|
0.51
|
36.4
|
|
CV
1/4 N3/8
|
1/4
|
NPT3/8
|
0.61
|
0.85
|
0.60
|
0.26
|
1.10
|
0.74
|
0.51
|
69.1
|
|
CV
5/16 N1/8
|
5/16
|
NPT1/8
|
0.34
|
0.57
|
0.65
|
0.32
|
1.00
|
0.38
|
0.57
|
19.4
|
|
CV
5/16 N1/4
|
5/16
|
NPT1/4
|
0.49
|
0.72
|
0.63
|
0.32
|
1.05
|
0.55
|
0.57
|
37.3
|
|
CV
5/16 N3/8
|
5/16
|
NPT3/8
|
0.59
|
0.87
|
0.61
|
0.32
|
1.13
|
0.74
|
0.58
|
69.4
|
|
CV
3/8 N1/4
|
3/8
|
NPT1/4
|
0.40
|
0.81
|
0.74
|
0.38
|
1.27
|
0.56
|
0.72
|
41.5
|
|
CV
3/8 N3/8
|
3/8
|
NPT3/8
|
0.47
|
0.88
|
0.71
|
0.38
|
1.28
|
0.74
|
0.72
|
71.6
|
|
CV
3/8 N1/2
|
3/8
|
NPT1/2
|
0.64
|
0.99
|
0.74
|
0.38
|
1.40
|
0.94
|
0.71
|
101.6
|
|
CV
1/2 N3/8
|
1/2
|
NPT3/8
|
0.59
|
0.98
|
0.82
|
0.50
|
1.35
|
0.74
|
0.83
|
75.4
|
|
CV
1/2 N1/2
|
1/2
|
NPT1/2
|
0.66
|
1.03
|
0.77
|
0.50
|
1.45
|
0.95
|
0.85
|
104.8
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Part
No.
|
Tube
OD
|
T
Pipe
Size
|
A
|
B
|
C
|
D
|
E
|
H
|
P
|
WEIGHT
(g)
|
|
CV
4 M5
|
4
|
M5
|
4.7
|
11.4
|
23.3
|
4.1
|
20.1
|
8.0
|
10.7
|
8.9
|
|
CV
4 M6
|
4
|
M6
|
5.2
|
10.6
|
13.9
|
4.1
|
20.2
|
8.0
|
10.6
|
9.1
|
|
CV
4 R1/8
|
4
|
R1/8
|
8.6
|
14.0
|
13.7
|
4.1
|
22.4
|
9.9
|
10.5
|
17.7
|
|
CV
4 R1/4
|
4
|
R1/4
|
0.5
|
0.7
|
0.6
|
0.2
|
26.3
|
14.0
|
12.8
|
36.8
|
|
CV
6 M5
|
6
|
M5
|
4.5
|
12.5
|
14.9
|
6.1
|
23.8
|
8.0
|
13.0
|
9.7
|
|
CV
6 M6
|
6
|
M6
|
5.8
|
11.5
|
15.1
|
5.2
|
22.4
|
7.1
|
11.9
|
9.8
|
|
CV
6 R1/8
|
6
|
R1/8
|
8.6
|
14.4
|
14.9
|
6.1
|
23.7
|
9.9
|
13.1
|
18.3
|
|
CV
6 R1/4
|
6
|
R1/4
|
12.1
|
18.1
|
14.9
|
6.1
|
26.0
|
14.0
|
13.1
|
36.4
|
|
CV
6 R3/8
|
6
|
R3/8
|
13.3
|
19.7
|
15.3
|
6.1
|
27.5
|
18.9
|
13.1
|
71.7
|
|
CV
8 R1/8
|
8
|
R1/8
|
8.5
|
14.6
|
15.9
|
8.2
|
25.5
|
9.9
|
14.6
|
19.1
|
|
CV
8 R1/4
|
8
|
R1/4
|
11.4
|
17.9
|
15.9
|
8.1
|
26.9
|
14.1
|
14.6
|
37.6
|
|
CV
8 R3/8
|
8
|
R3/8
|
13.4
|
20.4
|
16.1
|
8.0
|
29.4
|
19.0
|
14.5
|
73.0
|
|
CV
8 R1/2
|
8
|
R1/2
|
16.2
|
23.5
|
15.0
|
8.2
|
31.2
|
23.9
|
14.6
|
104.3
|
|
CV
10 R1/4
|
10
|
R1/4
|
11.5
|
20.7
|
19.1
|
10.1
|
31.7
|
14.0
|
18.3
|
40.3
|
|
CV
10 R3/8
|
10
|
R3/8
|
13.1
|
22.0
|
18.5
|
10.1
|
32.6
|
18.9
|
18.4
|
74.9
|
|
CV
10 R1/2
|
10
|
R1/2
|
16.1
|
24.7
|
19.1
|
9.9
|
35.8
|
23.9
|
18.1
|
108.3
|
|
CV
12 R1/4
|
10
|
R1/4
|
11.3
|
21.6
|
20.4
|
12.1
|
31.7
|
13.9
|
21.3
|
43.1
|
|
CV
12 R3/8
|
12
|
R3/8
|
13.0
|
23.2
|
21.0
|
12.2
|
35.4
|
19.1
|
21.0
|
77.2
|
|
CV
12 R1/2
|
12
|
R1/2
|
16.6
|
26.4
|
21.5
|
12.0
|
38.7
|
23.9
|
20.9
|
110.0
|
|
|
